Reverse Engineering

Is your PCB no longer manufactured or you need any replacements or capacity additions?

Lost your drawings and/or schematics from corrupted files?

Reverse engineer It! Reverse engineering of PCB’s is one of our specialties. Our PCB and PCA knowledge with extensive years of manufacturing experience, have enabled us to provide optimum PCB Reverse Engineering Services.

Our Reverse Engineering process involves:

• Understanding or studying the engineering sketches & specifications
• Feasibility and Electrical analysis of PCB
• PCB material analysis
• Component obsolescence / Replacement analysis
• Dimension analysis / Board outline drawings
• Process variation of reverse engineered board

At PCC, we have a dedicated team of engineers with proficiency and understanding of PCB Reverse Engineering Process. Our engineering expert team follow IPC design specifications and will work on simple to the most complex PCB/PCA projects.

PCC’s PCB Reverse Engineering Services can help you with:

• Change PCB layout
• Reverse complex multilayer cards
• Recompile microcontroller program and edit source code logic
• Re-engineer an old PCB design to current standards, using new components
• Re-engineering for cost reduction/obsolescence
• Embedded processor/DSP based designs updation
• Reproduce lost or missing PCB or mechanical manufacturing files
• Create new reference designs

A complete manufacturing documentation package will be offered to you under our Reverse Engineering Services. A few of them includes:

• Schematic capture files/Netlist
• Bill of Materials (BOM)
• Fabrication drawings
• Gerber files
• CAD design

PCC has 27 years of experience in servicing global clients. We provide unparalleled project based re-engineering and copying of your printed circuit boards (PCBs). Our comprehensive services include PCB Clone (copy of the schematics and BOM), PCB Prototype (produce prototypes for market evaluation or testing) and PCB assembly production (Mass production of PCB or Assembly).
