PCC specializes in rapid PCB assembly & system manufacturing services. We provide PCB Assembly Services for low and medium volume, high mix products, to varied customer markets globally. Our CCA, circuit card assembly lines are versatile for varied sizes and substrates types (FR4, Rogers, copper, duroid, ceramic, metal core aluminum, CEM 1, and CEM 3)
From multi-layered to flexible PCBs, we have expertise in each aspect of Printed Circuit Board Assembly & manufacturing services. We support simple, small boards to complex HDI boards in volume or prototypes.
Our factory is fully equipped with state-of-the-art, well maintained equipment for manufacturing both SMT (Surface Mount Technology) and TH (Through-Hole) technology PCB assemblies. Our services are highly personalized and we respond quickly to your needs at any stage of the partnership
From Design of Manufacturing (DFM), material sourcing, to testing, we provide in-house, end to end support services to deliver quick turnkey PCB assemblies and consignments.
Our PCBA Service Capabilities
- Design for manufacturability/testability (DFM/DFT) recommendations
- Low to High Volume SMT and TH mixed PCBAs
- Lead-free and leaded processing
- Fine pitch SMT, uBGA, MLF, CSP and 0201 Placement
- SMT lines set up to match PCB completion
- Prototype and pre-production electronic assembly
- Package on Package (POP) Capability
- Chip-on-board assembly
- X-ray and automated optical inspection (AOI)
- Placement speeds up to 70,000 cph
- SMT chip placement down to 0201
- Automated optical inspection (AOI)
- Solder paste inspection (SPI)
- BGA X-Ray inspection
- Conformal Coating and Potting/Encapsulation
- Final packaging and logistics
PCB Fabrication
We at PCC understand that no single PCB fabrication house can fulfill all the requirements of the customers. Hence, we have partnered with various local and offshore PCB fabrication houses to meet diversified needs of our clients. Our Capabilities cover:
- High density Multi-layered boards
- Electrical testing
- Double Sided Boards
- Photo plotting
- Single sided boards
- Data transfer via website
- BGA and fine pitch surface mounts
- Immersion tin and White tin finish
- UL 94V-0 and UL 796 approved
- Flash and Electrolytic gold plating
- Controlled Impedance
- LPI solder mask over bare copper
- Silk-screening
- Nickel and gold tab plating
PCB Layout and Design
PCC has experienced PCB designers who help in the successful delivery of effective electrical designs. Our designs are done by EE engineers with 25 years of product design experience. We design per IPC class II or Class III or to any given specifications. Our PCB designers have proven expertise in developing a physical layout for completed schematic designs.
- Using the best tools as per your needs, we perform 100% manual routing of the design’s physical layout
- Our quality assurance system ensures that the performance of final layout match exactly with the schematic design
- We perform complete PCB layout which includes: Schematic capture, development of library, construction, and verification of database, signal integrity, EMI checking and verification.
- We provide complete standardized documentation packages which include schematic capture files/Netlist, BOM (Bill of Materials), CAD design etc.
Why Choose PCC for PCB Assembly Services?
- One stop solution for PCB engineering, design, CCA and testing
- Leaded/RoHS-compliant
- AS9100D & ISO 9001:2015 Certified
