GIORDANO COLOMBO RC 110

Power range: 2.2-8.8 Kw/3-11.8 Hp

For use in woodworking, plastic, and light alloy machines, the RC 110 series automatic tool-change spindles are designed to be cooled by compressed air. The solution provides more efficient cooling than fan systems, while also allowing for a shorter overall length of the spindle.

Available in both ISO and HSK clamping systems, the tool holders are retained by special springs and are released by a pneumatic actuator. Proximity sensors are incorporated to ensure maximum safety and control of the tool change.

Details:

• Power range: 2.2-8.8 Kw/3-11.8 Hp
• RPM Range: 3,000 – 32,000
• Weight: 28Kg/62lbs
• Tool Holder: ISO 30/HSK 50/HSK 63
• Cooling: Compressed Air
