HAZET-WERK - Hermann Zerver GmbH & Co. KG

Product information

Application:

For working quickly in confined spaces due to compressed form and air inlet that can be pivoted by 150°

• Handy impact screwdriver, 108 Nm loosening torque

• For installing / removing the front cover of the timing chain on VW Polo (type 6R, 6C) with 1.2 l TSI engine, for example

• Oil pan screw connections,

• Valve cover screw connections

• Wheel arch and engine casings

• Reversing switch for easy change in direction without re-gripping

• Completely closed head avoids the entry of swarf etc.

• Reduced vibrations

• Powerful pin clutch mechanism

• Air connection inlet: Inside thread (IG) 12.91 mm (1/4″)

• Coupler plug: nominal size 7.2 (included)

• Hose diameter (recommended): 10 mm

• Working pressure (bar): 6.3

• Sound power level: 109 db(A) Lp W

• Vibration acceleration: 6.74 m/s2

• Forward and reverse: three-stage (forward and reverse rotation) to reduce power on sensitive screw connections

• Total length: 139.1 mm

• Output: Square, solid 10 mm (3/8 inch)

• Net weight: 0.55 kg

• Maximum loosening torque: 108 Nm

• Sound pressure level: 98 dB(A) Lp A

• Revolutions per minute: 12000

• Air requirement: 59 l/min (1 l/sec)
