3D Geometry Models RF SGEdit

3D Geometry ModelsRF::SGEdit

• RF::SGEdit is the module for editing 3D geometry models of RF::Suite.
• RF::SGEdit displays a clear hierarchical data structure of 3D geometry models. The edit function removes unneeded model parts or adds additional ones. Missing kinematizations are easily added and existing ones are easily tested.
• RF::SGEdit's integrated measurement capabilities make it easy to determine the dimensions of 3D geometry models. These features make RF::SGEdit indispensable for model preparation for virtual commissioning.
